Custom circuits involve designing and building unique electronic circuits tailored for specific amateur radio tasks. This allows operators to create devices that are not commercially available, enhancing radio performance and experimenting with innovative solutions. Custom circuits can be used for various purposes, including RF signal processing, audio filtering, or creating specialized interfaces.


General Ham Resources

These custom circuit projects provide a way for amateur radio enthusiasts to innovate and optimize their setups, solving unique problems and enhancing overall station capabilities.

  1. Bandpass Filters: Custom bandpass filters can be used to improve reception by reducing interference from unwanted frequencies. Building a bandpass filter using inductors and capacitors helps to ensure clear signals. Bandpass Filter Kit can be a great starting point for building your own filter.

  2. Audio Notch Filter: A custom audio notch filter can help remove unwanted noise from a received signal, making voice communication clearer. These can be made with op-amps and resistors to target specific frequencies. Op-Amp IC is often used in such projects.

  3. RF Signal Amplifier: Amplifiers are used to boost weak signals for better reception or transmission. A simple RF amplifier circuit can be designed using transistors like the 2N2222 NPN Transistor to increase the power of low-level signals.

  4. CW Keyer Circuit: Custom circuits can also be used to create a CW keyer for sending Morse code. By using transistors and timing components, you can make a circuit that automatically sends predefined messages. Keyer Circuit Kit is a popular choice for such projects.

  5. SWR Bridge: An SWR (Standing Wave Ratio) bridge helps monitor the efficiency of an antenna by measuring reflected power. Building a simple SWR bridge using diodes and resistors can help operators optimize antenna performance. SWR Bridge Components are available to get started.

Local Club Activities

Several RARS hams enjoy building custom circuits. Even down to the board-etching level!

Look on our Discord server #diy-projects channel for more info and to ask questions.
